Dette produktet støtter ikke 3G-SDI Level B, kun Level A. Hvis et level B-signal blir tilført enheten, vil skjermen vise en gråskala, og en advarsel vil komme opp på skjermen.
For kompatibilitet med miksere og kameraer fra Blackmagic Design kan mikseren eller kameraet konfigureres til å bruke Level A i stedet for Level B. Dette medfører ingen negative konsekvenser i form av reduserte muligheter eller kvalitet.
SDI to HDMI Converter with Display
You can easily monitor in/output resolution, cable length and eye-pattern at once. LUMANTEK's ez-SHV+ has a SDI LOOP output. Through the LCD screen, you can monitor incoming video. By using the 'dip switch', you can select the resolution from 480i to 1080p. You can also control the LCD Brightness and screen ratio.
24/7 Video Monitoring
Through the built-in 2.7" TFT LCD screen, you can monitor eye-Pattern, in/output source resolution, and cable length.
Audio Level Meter
Monitoring your audio visually is easy with the on-screen audio meter.
Wall Mountable
ez-SHV+ includes a wall mount bracket which can also be used for fixing the converter to tripods or other things using a regular cable strap.
Automatically Detect Cable Length
ez-SHV+ detects cable length automatically up to 190 m at 3G-SDI. Cable length will be shown as 'SHORT', 'MEDIUM' and 'LONG'.
Low Power Consumption
The Maximum power consumption of ez-SHV+ is less than 3 watts. Acceptable voltage ranges from 5v ~ 18v, giving the user more flexibility for powering the device.
Global Power Adaptor
All ez-Converters come with AC/DC power adaptor included.
Feature-Rich Converter
Discover how the ez-SHV+ can make your work easier.
